Multi Directional Drive XL 3D /DMX/02

Multidimensional rotation wonder with video and laser projection possibility: The Multi Directional Drive XL 3D /DMX/02 is OASE's largest threedimensional swivel drive with a rotating axis. It impresses with phenomenal and dynamic water effects.

In combination with the nozzle Fan Jet 30 – 11 E, the Multi Directional Drive XL 3D /DMX/02 forms gigantic water fans, which could be used statically as an approximately 31m² large screen for breathtaking laser and projection shows. With a pivoting range of up to 180° on the X-axis and up to 165° on the Y-axis, plus an endless rotation of the 360° Z-axis (one rotation per second) the Multi Directional Drive XL 3D (MDD XL 3D) is unlimited in its movement. This enables the creation of impressive water effects. A fountain height of up to 9 m can even be achieved with the Fan Jet 30 – 11 E nozzle. The innovative design of the MDD XL 3D enables the nozzle (Fan Jet 30 – 11 E) to be turned and folded back to its park / default position – thus hiding it completely under water at a water level of 850 mm. The maximum pivoting range at this level is 150° on both the X and Y axes.
